The H130 is derived from Airbus’ Ecureuil family of light helicopters, which is renowned for its performance, reliability, safety, and multi-mission capability.
Performance
Hover ceiling OGE | 2,957 m |
Hover ceiling IGE | 3,429 m |
Fast cruise speed | 606 km |
Max range with standard fuel tanks at SL | 606 km |
Max endurance with standard fuel tanks SL | 4 hr, 00 min |
Flight envelope (temperature) | -40°C to ISA +35°C limited to 50°C |
Max altitude flight | 7,010 m |
Dimensions
D-value | 12.64 m |
Rotor diameter | 10.69 m |
Cabin internal volume | 3.70 m3 |
Characteristics
Crew + passengers | 1 pilot + up to 7 passengers or 2 pilots + up to 6 passengers |
Max takeoff weight (MTOW) | 2,500 kg |
Max takeoff weight with external load | 3,050 kg |
Useful load | 1,039 kg |
Standard fuel tank capacity | 425 kg |
Engine type | Safran Helicopter Engines Arriel 2D |
Takeoff power | 710 kW / 952 shp |
Performance
Hover ceiling OGE | 9,700 ft |
Hover ceiling IGE | 11,250 ft |
Fast cruise speed | 128 kts |
Max* range with standard fuel tanks at SL | 327 NM |
Max* endurance with standard fuel tanks SL | 4h00min |
Flight envelope (temperature) | -40°C to ISA +35°C limited to 50°C |
Max altitude flight | 23,000 ft |
Dimensions
D-value | 41.47 ft |
Rotor diameter | 35.07 ft |
Cabin internal volume | 130.70 cu. ft |
Characteristics
Crew + passengers | 1 pilot + up to 7 passengers or 2 pilots + up to 6 passengers |
Max takeoff weight (MTOW) | 4,512 lb |
Max takeoff weight with external load | 6,724 lb |
Useful load | 2,306 lb |
Standard fuel tank capacity | 937 lb |
Engine type | Safran Helicopter Engines Arriel 2D |
Takeoff power | 710 kW / 952 shp |
Photos and videos
Fly Blade, Inc. (“Blade”) has partnered with Sundance Helicopters based in Las Vegas, NV, to offer helicopter taxi flights on an H130 to Black Rock City for the 2018 Burning Man event, turning what is for many an 8-hour drive into a 45-minute journey. With its low sound levels, large cabin and panoramic windows, the H130 is a leader in the tourism and passenger transport sector.
