H160

Technical information

Designed with passenger safety and comfort in mind, Airbus’ multi-mission H160 is one of the world’s most technologically advanced helicopters.

Technical Description

Performance

Recommended cruise speed	255 km/h
Max range with standard fuel tanks	880 km
Max endurance with standard fuel tanks	4 h 30 min
Flight envelope (temperature)	-20°C to ISA +37°C limited to 50°C
Max flight altitude	6,096 m
Hover ceiling IGE	2,835 m

Dimensions

D-value	15.67 m
Rotor diameter	13.4 m
Internal cabin volume	up to 7.3 m3

Characteristics

Crew + passengers	1 or 2 pilots + up to 12 passengers
Max takeoff weight (MTOW)	6,050 kg
Useful load	Up to 2,000 kg
Engine	2 x Safran Helicopter Engines Arrano 1A
Standard fuel tank capacity	1,120 kg
Takeoff power	955 kW / 1,280 shp

Performance

Recommended cruise speed	138 kts
Max range with standard fuel tanks	475 NM
Max endurance with standard fuel tanks	4 h 30 min
Flight envelope (temperature)	-20°C to ISA +37°C limited to 50°C
Max flight altitude	20,000 ft
Hover ceiling IGE	9,300 ft

Dimensions

D-value	51.41 ft
Rotor diameter	43.96 ft
Internal cabin volume	up to 257.8 cu.ft

Characteristics

Crew + passengers	1 or 2 pilots + up to 12 passengers
Max takeoff weight (MTOW)	13,338 lb
Useful load	4,409 lb
Engine	2 x Safran Helicopter Engines Arrano 1A
Standard fuel tank capacity	2,469 lb
Takeoff power	955 kW / 1,280 shp

Configurations

Offshore transportation

12-passenger seating is made up of three rows of four seats. Cabin flexibility provides the possibility to install a stretcher in place of the centre row.

Helicopter emergency medical services (HEMS)

Depending on the EMS kit, the cabin can be arranged with one or two stretchers, in longitudinal or transversal positions.

Public services

To meet customer needs, the H160 facilitates cabin layouts and the integration of equipment for maritime search & rescue and aerial law enforcement missions.

Private and business aviation

The H160 can be configured for one to two pilots and up to 10 passengers in applications that meet the high standards of private and business aviation.
